Lead LDTS4000 stringer with DRlink layup

Second Hand LDTS4000 Multi-Busbars PV cells soldering stringer, manufactured by Wuxi Lead Intelligent Equipment – Lead, is available in Europe with kit for M6 – 9BB Full Cells.

It is a fully automatic photovoltaic cells stringing machine, offered used and professionally maintained.

Key Technical Details:

• Capacity: up to 3.800 half cells/hour – up to 3.000 full cells/hour
• Power supply: 380V, 50Hz, three-phase
• Power consumption: Peak: 40 kW, Average: 20 kW
• Air supply pressure: 0.6–0.8 MPa
• Average air consumption: 1.000 l/min
• Weight: approx. 6.500 kg
• Dimension: 6960 × 1860 × 2300 mm

Automatic Strings Layup Machine is manufactured by Suzhou DRlink Automation Technology and it’s equipped with an HMI touchscreen.

• Dimensions (W × D × H): 3800 × 2600 × 2000 mm
• Weight: approx. 1.800 kg
• Power supply: AC 380V ±10%, 50/60Hz, three-phase (5-wire)
• Max power consumption: 8 kVA
